  • SELECTION


Wire to Board Connector
  • Product
  • PITCH
    mm
  • Series No.
  • Type
  • Pin No.
  • Specifications
  • Remark
  • 2.00
  • 2001S-xx-ST/RT-S
  • Single Row Straight / Right Angle SMT
  • 2 ~ 16
  • Current Rating : 1A~3A AC/DC
    Voltage Rating : 100V AC/DC
    Contact Resistance : 20mΩ Max.
    Withstanding Voltage : 800V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 2.00
  • 2001D-2*xx-ST/RT
  • Dual Row Straight / Right Angle DIP
  • 6 / 8 / 10 / 12 / 14 / 16 / 18 / 20 / 22 / 24 / 26 / 28 / 30 / 32
  • Current Rating : 1A~3A AC/DC
    Voltage Rating : 100V AC/DC
    Contact Resistance : 20mΩ Max.
    Withstanding Voltage : 800V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 2.00
  • 2001PA-xx-ST/RT-D
  • Single Row Straight / Right Angle DIP W/ POST
  • 2 ~ 15
  • Current Rating : 1A~3A AC/DC
    Voltage Rating : 100V AC/DC
    Contact Resistance : 20mΩ Max.
    Withstanding Voltage : 800V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 2.00
  • 2001PA-xx-ST/RT-S
  • Single Row Straight / Right Angle SMT
  • 2 ~ 4 / 10 ~ 15
  • Current Rating : 1A~3A AC/DC
    Voltage Rating : 100V AC/DC
    Contact Resistance : 20mΩ Max.
    Withstanding Voltage : 800V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 2.50
  • 2501-xx-ST/RT
  • Single Row Straight / Right Angle DIP
  • 2 ~ 20
  • Current Rating : 3A AC/DC
    Voltage Rating : 250V AC/DC
    Contact Resistance : 20mΩ Max.
    Withstanding Voltage : 800V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 2.50
  • 2511-xx-ST/RT
  • Single Row Straight / Right Angle DIP
  • 2 ~ 20
  • Current Rating : 3A AC/DC
    Voltage Rating : 250V AC/DC
    Contact Resistance : 20mΩ Max.
    Withstanding Voltage : 800V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 2.50
  • 2501H-xx-ST/RT
  • Single Row Straight / Right Angle DIP
  • 2 ~ 12
  • Current Rating : 3A AC/DC
    Voltage Rating : 250V AC/DC
    Contact Resistance : 20mΩ Max.
    Withstanding Voltage : 800V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 2.50
  • 2501J-xx-ST / RT(RG-S)
  • Single Row Straight / Right Angle DIP
  • 2 ~ 20
  • Current Rating : 3A AC/DC
    Voltage Rating : 250V AC/DC
    Contact Resistance : 20mΩ Max.
    Withstanding Voltage : 800V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 3.00
  • 3001-xx-ST/RT
  • Dual Row Straight / Right Angle DIP
  • 2 / 4 / 6 / 8 / 10 / 12 / 14 / 16 / 18 / 20 / 22 / 24
  • Current Rating : 5A AC/DC
    Voltage Rating : 250V AC/DC
    Contact Resistance : 10mΩ Max.
    Withstanding Voltage : 1,500V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
  • 3.96
  • 3961-xx-ST / RT
  • Single Row Straight / Right Angle DIP
  • 2 ~ 20
  • Current Rating : 5A AC/DC
    Voltage Rating : 250V AC/DC
    Contact Resistance : 10mΩ Max.
    Withstanding Voltage : 1,500V AC/minute
    Insulation Resistance : 1,000MΩ Min.
    Temperature Range : -25℃ ~ +85℃
