Wire to Board Connector
Product
PITCH
mm
Series No.
Type
Pin No.
Specifications
Remark
2.00
2001J-xx-ST/RT
Single Row Straight / Right Angle DIP
2 ~ 16
Current Rating : 1A~3A AC/DC Voltage Rating : 100V AC/DC Contact Resistance : 20mΩ Max. Withstanding Voltage : 800V AC/minute Insulation Resistance : 1,000MΩ Min. Temperature Range : -25℃ ~ +85℃
2.00
2001S-xx-ST/RT-S
Single Row Straight / Right Angle SMT
2 ~ 16
Current Rating : 1A~3A AC/DC Voltage Rating : 100V AC/DC Contact Resistance : 20mΩ Max. Withstanding Voltage : 800V AC/minute Insulation Resistance : 1,000MΩ Min. Temperature Range : -25℃ ~ +85℃
